Difficulty: expert
Content
Learning Objectives
After reading this article, you’ll be able to:
- prepare on-site locations for Zens installation
Installation is done by an installation partner of Spacewell. This cannot be done by the customer.
Prerequisites
- For the Smart PuK Visual / wireless charger:
A hole with a diameter of 81 mm needs to be drilled in the table at the position where the Smart PuK Visual should be placed.
- 230V power plug
- The motion sensor needs to be installed in the center at the bottom of the desk.
The ideal distance from the front of the desk to the front of the sensor is 300 to 350 mm
- Provide an unobstructed view of the sensor for an optimal detection area
- The motion sensor will be screwed with two screws on the underside of the desk
